Telescope :
- Length : 215mm (8.46 in.)
- Magnification : 32x
- Objective Aperture : 42mm (1.65 in.)
- Resolving Power : 3 in
- Field of View : 1°20’, (2.3m/7.5 ft.)
- Min. Focus from end of telescope : 0.2m (7.9 in.)
- Min. Focus from instrument center : 0.3m (1 ft.)
- Image : erect
- Stadia Constant : 0
- Stadia Ratio : 100
- Focusing Knob : 2-speed
- Sighting Aid : Peep Sight
Accuracy :
- Without Micrometer : 0.7mm (0.03 in.)
- With Micrometer : 0.5mm (0.02 in.)
Compensator :
- Type : Pendulum compensator with magnetic damping system
- Setting Accuracy : 0.3 in
- Working Range : ±15 ft.
Circular Level :
- Sensitivity : 10 ft./2mm
Horizontal Circle :
- Diameter : 103mm (4.1 in.)
- Minimum Division : 1°/1gon
General :
- Water Resistance : IPX6 (IEC 60529:2001)
- Operating Temperature : -4°F to +122°F (-20ºC to +50ºC)
- Width : 5.12 in. (130mm)
- Length : 8.46 in. (215mm)
- Heigth : 5.51 in. (140mm)
- Weigth : 4.1 lbs. (1.85kg)
